Medium DIY Van or RV Rooftop Solar to Battery SYSTEM

$3,599.00

Categories: , ,

Description

Medium DIY Van or RV Rooftop Solar to Battery SYSTEM: $3599

Includes 5-year warranty and FIVE YEARS of technical support!!

Package 1: 400 Watts Flexible Solar Panels, + MPPT Charge Controller, + Plug & Play Backboard, + Technical Manual + FREE INSTALLATION  SUPPORT*

Package 2: Up to 200 Watts Hard or Soft Solar Panels, + Lithium Charge Controller, + 100ampHour LITHIUM Deep-cycle Battery, + Plug & Play Backboard, + Technical Manual + FREE INSTALLATION  SUPPORT*

Because, let’s face it, either you have the guts to install this yourself, or ya don’t. If y’all are like me though, you’d LOVE to do it yourself, but just don’t have the time to learn how.. Enter: Indie Solar. We’ll take care of the design and installation plan  to give you the ultimate RV solar system, yet let you save the installation cost and do it yourself! You can call us, FaceTime us, have a personal meeting with us to understand your solar system over the next FIVE years. If solar power is the wild-west, this is a hell of a time to get in on the game of #vanlife and #yourDestinty

*You may come park your trailer at our shop in Austin, Texas and we’ll provide on-site support. Or you may schedule up to 4 hours of Video Conference Calls

Whether you have a backyard gazebo that needs power to a vintage trailer-made-Airbnb to your off-the-factory-floor Class A that you plan to retire in, we have you covered.

Specifications

RENOGY 100W ECLIPSE SOLAR PANEL RENOGY 100W MONOCRYSTALLINE SOLAR PANEL
Maximum Power: 100W Maximum Power: 100W
Maximum System Voltage:600V DC Maximum System Voltage: 600V DC
Open-Circuit Voltage (Voc): 21.2V Open-Circuit Voltage (Voc): 21.6V
Short-Circuit Current (Isc): 6.10A Short-Circuit Current (Isc): 6.24A
Optimum Operating Voltage (Vmp): 17.7V Optimum Operating Voltage (Vmp): 17.9V
Optimum Operating Current (Imp): 5.70A Optimum Operating Current (Imp): 5.72A
Weight: 15.0lbs Weight: 16.5lbs
Dimensions: 40.8 X 20.7 X 1.4 inches Dimensions: 42.2 X 19.6 X 1.38 inches
RENOGY 16FT 10AWG TRAY CABLES (A PAIR) RENOGY MC4 BRANCH CONNECTORS
Length: 16ft Withstanding Voltage: 1000V DC(TUV), 600V(UL)
AWG: 10 Protection Degree: IP67, mated
Rating Voltage: 600V Wiring Size Range: 10, 12, 14 AWG
Temperature: -40°F to +185°F Temperature: -40°F to +194°F
RENOGY ADVENTURER – 30A PWM NEGATIVE-GROUND CHARGE CONTROLLER WITH LCD DISPLAY RENOGY CABLE ENTRY HOUSING
Nominal Voltage: 12 VDC Material: UV-resistant ABS Plastic
Rated Charge Current: 30A Weight (each component): 7.9 oz.
Max. PV Input Voltage: 25 VDC Recommended Adhesive: Sikaflex 252 or alike
Max. PV Input Power: 400W (12V) Dimensions (l x w x h): 4.7 x 3.9 x 2.0 in
Cable Gland Diameter Range: 6mm – 12mm
MOUNTING Z BRACKETS (SET) RENOGY 30FT 10AWG MC4 ADAPTOR KIT (A PAIR)
Eight Long Cap Bolts and Four Short Bolts Length: 30ft
Four Spring Washers and Four Washers AWG: 10
Four Z Shape Solar Panel Brackets Rating Voltage: 600/1000V
Four Nuts Temperature: -40°F to +185°F
RENOGY BT-1 BLUETOOTH MODULE
Input Voltage: 5V-12V
Communication Range: ≤15m
Dimensions: 2.6 X 2.01 X 0.61 In
Weight: 120 g (4.2oz)

WARRANTY INFORMATION

Panels 25-year power output warranty: 5 year/95% efficiency rate, 10 year/90% efficiency rate, 25-year/80% efficiency rate

5-year material and workmanship warranty
Accessories 1-year material warranty
